Anyone had experience with Silver 5-ATz complexes such as [(2Ag)5-ATz] NO3 or ClO4? The perchlorate is mentioned in engager’s tetrazole write up and a patent but there doesn’t seem to be much discussion on it. I tried to make the nitrate the other day according to klapotke’s procedure (https://pubmed.ncbi.nlm.nih.gov/19105192/) but it didn’t seem to yield anything that great. To start, 5-ATZ doesn’t dissolve that great in conc (anything higher than azeo %) Nitric Acid, and if you add too much water, the complexation time with AgNO3 can be ruined by just dumping out the Silver salt of 5-ATz. Too high conc of acid will form the 5-ATz nitrate salt instead which has low solubility as well and hinders complexation as well.

My product crashed out of the sol immediately on addition of AgNO3 to the 5-ATz/HNO3 mix as an off-white precipitate that started to yellow to a pastel yellow on air drying on a filter.

The product is supposed to detonate on flame contact and indirectly at 298C. For me, it does crackle faintly but I can’t seem to get it to dry. I would wager it’s like AgNTz in that it is a pain to detonate when wet but really goes when dry, but I can’t get this complex to dry to see anything amazing.

This salt could be a great alternative to LA, nitrotetrazoles, and such since it’s so seemingly easy to prepare, but I can’t get make it to match klapotke’s results. -My HNO3 and AgNO3 are pure and my 5-ATz is decently pure so idk.

This week I tried the nitrate salt, with similar results. I´ve used 65 % reagent grade nitric acid (I guess close to azeotropic is what they mean with "concentrated", otherwise they state "fuming" which is close to 100 %) and had also problems to dissolve the 5-ATZ. A warm water bath helped me to dissolve it.

Then I added the AgNO3 solution dropwise. Each drop changed immediately into a cheese-like white consistency after contact with the acidic 5-ATZ solution, but redissolved after some swirling. After several drops added, the solution remains turbid and it was no longer possible to redissolve it even with prolonged swirling.

After complete addition of the silver nitrate solution the whole reaction was dense white, like yoghurt. Here is a clear difference to the cited reference (Klapötke et al), they state that after addition of water the reaction mixture becomes turbid and some precipitate was formed.

I´ve also added some water, but it was impossible for me to see if the additional water produced additional precipitate.

After standing over-night I´ve filtered the precipitate, washed three times with distilled H20, then three times with IPA and let it dry over-night.

In contrast to your result, my product remains pure white with a flour-like consistency, but the behaviour against flame seems to be the same. No ddt, just a flash (not really impressive). See attached video.

So I would like to know what was wrong if you, microtek and I were unable to repeat the deceptive easy preparation.

And BTW my yield was much lower than cited (from 2,5 gram silver nitrate more than 4,2 gram was expected, but I got only 2,6 gram - something really went wrong).

Attachment: Disilver-5-aminotetrazole nitrate.mp4 (732kB)
This file has been downloaded 172 times

dettoo456 - 20-1-2024 at 10:46

I’d attribute the yellow color I got from pure lazy experimental methods - I just had all of the starting materials lying around so I thought I’d prep the complex in <15min. I didn’t even measure yield. Besides that though, the product SHOULD detonate on flame contact, albeit weaker than AgNTz or Pb(N3)2. Mine was only able to detonate after drying fully (sitting out at room temp for a couple of days).

It had trouble combusting in contact with a fuse though, in contrast to the more standard primaries like AgNTz.

If you’re paranoid about temperature stability (or friction and shock at that), I’d recommend the complex for cap designs but besides that, standard AgNTz or DBX-1 seems to be, ironically, easier to handle.

I’ll try to report stability results in the future with samples though.

Nemo_Tenetur - 20-1-2024 at 13:44

Well, Klapötke mentioned a possible explanation:

However, it must be noticed that the crystalline state of the sample is of extreme importance when testing the sensitivity of energetic compounds, i.e., crystalline compounds tend to show higher sensitivities to impact and friction.

This could be an explanation for the weak response of my amorphous flour-like sample to flame, but not for immediate precipitation after dropwise addition of the silver nitrate to the acidic 5-ATZ solution.

The experimental parameters are well defined.

Etanol - 20-1-2024 at 22:09

This could be an explanation for the weak response of my amorphous flour-like sample to flame, but not for immediate precipitation after dropwise addition of the silver nitrate to the acidic 5-ATZ solution.

No. The crystalline state affects mechanical sensitivity, but has little effect on DDT.

Etanol - 6-3-2024 at 22:03

Quote: Originally posted by MineMan

Those sensitivities are impressive. The copper version of NAP is 2J impact but 20N friction if I remember. I regard friction as more important. There are primaries that are immune to friction. This does look like a complex snyth tho. Wish the friction was less sensitive

Excuse me, what is NAP? Nickel aminotetrazole perchlorate?

upd
O, I find, Nickel aminoguanidine diperchlorate

[Edited on 7-3-2024 by Etanol]

ManyInterests - 2-4-2024 at 08:02

I wasn't sure where else to put this, so I am asking here.

I made some more NHN yesterday. Using 130ml of 95% (closer to 96%) ethanol, 43.5g of hydrazine sulfate, and 26.6g sodium hydroxide. The only difference is I was using bought nickel nitrate and not made. I dissolved 63g of nickel nitrate in 150ml of water with 0.005% dextrin by weight of the NN. The temperature did rise over 70C a few times which caused me concern.

I put in around 50ml of the solution, or a little less. But it was an excess. Everything appeared to run smoothly. My vacuum pump had issues so it was effectively gravity filtered. As I washed out the excess nickel nitrate with copious amounts of warm water and around 350ml of 95% ethanol.

The color is mostly OK. But there is that little tinge in it that bothers me. It is drying as of now, but I am wondering if it is something I should be concerned about.

I never saw any information on recrystalizing NHN. But I did hear that ammonia (I have 27% ammonia) works as a solvent. Would it dissolve it and simply be able to crash out the impurities? If they are impurities that is.

Microtek - 2-4-2024 at 23:43

I don't know how labile the hydrazine ligands are, but I would expect at least some of them to be replaced with the rather similar ammonia ligands if you try treating the NHN as a simple salt. Ammonia is more volatile than hydrazine, so maybe you could evaporate it off to reform the hydrazine complex, but I don't think it likely.

ManyInterests - 3-4-2024 at 03:45

Well it probably wasn't something major since the NHN appears to be of good quality.

But there is one major problem: I was expecting at least 12g of yield based on all the previous attempts I made. But I only got 4! I am legit baffled as to what happened.

My estimates that is I did not freebase enough hydrazine from my hydrazine sulfate, and the heating went out of control for a bit. The other thing is that my nickel nitrate solution was too concentrated. I diluted what I had to resemble more of what people showed when they used it (it is still quite dark green).

I am going to try again with similar quantities but I will take more care with heating on my mantle to not allow it to rise above 63 or 65c. My new mantle is very powerful, but a little finicky.

Nemo_Tenetur - 5-4-2024 at 13:52

Was the filtrate almost colorless (a very weak blue) or turquoise to green? From my experience, concentrated nickel nitrate solution doesn´t hurt the yield, but I´ve always performed the synthesis with commercially hydrazine hydrate solution.

Commercially available nickel nitrate is almost always the hexahydate, because it is VERY hard to get the anhydrous salt. Did you respect this within your yield calculation?

And, by the way, the use of dextrin is pretty useless IMHO. I know the patent which claim a higher density, but I can´t confirm this. From my experience - dozens batches - the highest bulk density is obtained with concentrated solutions. I always use a few percent hydrazine excess to ensure complete consumption of the nickel and to avoid an incomplete complexation.

I´ve seen a paper with an NHN accident ("spontaneous explosion of a normally stable complex salt" by Herbert Ellern an Donald E. Olander ) where an incomplete complexation lead to an unstable product with self-deflagration even when moist!

Just for your information that even with such a "safe" primary shit can happen.

ManyInterests - 6-4-2024 at 18:10

Was the filtrate almost colorless (a very weak blue) or turquoise to green? From my experience, concentrated nickel nitrate solution doesn´t hurt the yield, but I´ve always performed the synthesis with commercially hydrazine hydrate solution.

Commercially available nickel nitrate is almost always the hexahydate, because it is VERY hard to get the anhydrous salt. Did you respect this within your yield calculation?

And, by the way, the use of dextrin is pretty useless IMHO. I know the patent which claim a higher density, but I can´t confirm this. From my experience - dozens batches - the highest bulk density is obtained with concentrated solutions. I always use a few percent hydrazine excess to ensure complete consumption of the nickel and to avoid an incomplete complexation.

I´ve seen a paper with an NHN accident ("spontaneous explosion of a normally stable complex salt" by Herbert Ellern an Donald E. Olander ) where an incomplete complexation lead to an unstable product with self-deflagration even when moist!

Just for your information that even with such a "safe" primary shit can happen.

I am aware that danger can happen. this is why I treat all energetics with the utmost respect.

I've bumped up another thread about this for further discussion. I am not happy with what is going on.

EF2000 - 7-4-2024 at 01:50

I always use a few percent hydrazine excess to ensure complete consumption of the nickel and to avoid an incomplete complexation.

I´ve seen a paper with an NHN accident ("spontaneous explosion of a normally stable complex salt" by Herbert Ellern an Donald E. Olander ) where an incomplete complexation lead to an unstable product with self-deflagration even when moist!

Just for your information that even with such a "safe" primary shit can happen.

Mentioned paper (doi: 10.1021/ed032p24) says that in another, more serious accident hydrazine hydrate was used in 5% excess. And that hydrazine occluded in product's crystal, higher complexation, or contamination by combustible organics are possible causes of spontaneous explosion. Meaning that both excess and deficiency of hydrazine can be dangerous.
Conclusion: Hydrazine is generally unpleasant compound.

Attachment: ellern1955.pdf (1MB)
This file has been downloaded 151 times

Laboratory of Liptakov - 7-4-2024 at 02:35

When I reading last problems about hydrazine, respectively about NHN, maybe will better focusing on SA-DS. Yes, sensitivity is higher and is it full primary, but preparation is very easy and results are constant. I know, this mention is out of thread..... :cool:

ManyInterests - 7-4-2024 at 05:30

Quote: Originally posted by Laboratory of Liptakov

When I reading last problems about hydrazine, respectively about NHN, maybe will better focusing on SA-DS. Yes, sensitivity is higher and is it full primary, but preparation is very easy and results are constant. I know, this mention is out of thread..... :cool:

I made successful NHN several times before. I think what happened wrong is that I didn't freebase it correctly. It was simply too cold to freebase (all reagents were stored in a fridge for days to cool). I was not aware that it wouldn't freebase or react if it is too cold.

All previous successful times I did it at room temperature but simply kept everything cooler in an ice bath.

Remember LL, this is the first time I ran into issues with NHN synthesis! :p

Nemo_Tenetur - 7-4-2024 at 06:13

I had only one failure with NHN. This batch was of very low bulk densitiy, difficult to dry and hard to ignite. The color was more like pale pink, precipitated in high dilution.

Then I switched back to concentrated solutions and everything was fine again. In general, I think it´s good primary. But you require several hundred milligram and some containment for reliable DDT. Such a quantity produce alot of nickel dust, this isn´t the healthiest thing.

ManyInterests - 7-4-2024 at 07:58

I had only one failure with NHN. This batch was of very low bulk densitiy, difficult to dry and hard to ignite. The color was more like pale pink, precipitated in high dilution.

Then I switched back to concentrated solutions and everything was fine again. In general, I think it´s good primary. But you require several hundred milligram and some containment for reliable DDT. Such a quantity produce alot of nickel dust, this isn´t the healthiest thing.

That is true. But with an ETN mixed in at a 1:1 ratio or with other mixtures it can be an extremely powerful initiating agent. NHN has been in use in commercial detonators for decades now. It isn't an unproven new thing.

I've made a lot of progress with using NHN detonators and I plan on continuing with them.

For LL. I wish to inform him that CHP and LL8 are on the table.

Etanol - 8-4-2024 at 04:34

Quote: Originally posted by EF2000

(doi: 10.1021/ed032p24)

Electrostatic discharge?

Etanol - 13-4-2024 at 12:29

Try to change mixing method ATz and AgNO3:
add ATz to AgNO3, not AgNO3 to ATz.
Try don't add HNO3.
Add 5mmol hot ATZ solution into 10mmol solution of AgNO3, cold it.

[Edited on 13-4-2024 by Etanol]

Etanol - 30-4-2024 at 18:46

Are exists base complexes of 5-aminotetrazole and Ni or Cu or Co and NO3 or ClO4 anions?

[Ni(ATZ)n](ClO4)2
[Ni(ATZ)n](NO3)2
[Co(ATZ)n](ClO4)2
[Co(ATZ)n](NO3)2
[Cu(ATZ)m](ClO4)2
[Cu(ATZ)m](NO3)2

m=? n=?

Complexes of Co(III)?
[Co(ATZ)n](ClO4)3
[Co(ATZ)n](NO3)3

upd
from wiki: "The N-4 is basic as indicated by its binding to metal halides, such as the coordination complex [CoCl2(aminotetrazole)4"
Then only [Cu(ATZ)4](ClO4)2 has acceptable oxygen ballance:

[Cu(CH3N5)4](ClO4)2=>CuCl2+10N2+6H2O+2CO+2C

[Edited on 1-5-2024 by Etanol]

Microtek - 1-5-2024 at 12:33

As I commented in another thread, there definitely is a Ni complex with aminoTRIazole, so I find it very likely that it forms one with 5-ATz as well. I do have some 5-ATz and some Ni(NO3)2 so I could test if something precipitates either on mixing or when adding a perchlorate (or chlorate) solution.

Etanol - 1-5-2024 at 14:37

As I commented in another thread, there definitely is a Ni complex with aminoTRIazole, so I find it very likely that it forms one with 5-ATz as well. I do have some 5-ATz and some Ni(NO3)2 so I could test if something precipitates either on mixing or when adding a perchlorate (or chlorate) solution.

Thanks. But I do not think that Ni complex will be effective. It contains very little oxygen:
[Ni(CH3N5)6](ClO4)2=>NiCl2+15N2+8H2O+H2+6C

According to the article
"SPIN TRANSITION IN HETEROANION COMPLEXES IN THE Fe2+-4-AMINO-1,2,4-TRIAZOLE–NO3−SO4−SYSTEM" (10.1134/s0022476620090048) from sci-hub

,there is a complex Fe(ATrz)3(NO3)2⋅nH2O (ATrz = 4-amino-1,2,4-triazole),
which means that the 4-amino-1,2,4-triazole is bivalent as ligand.
Then ATrz complexes are more effective, especially copper:

[Ni(C2H4N4)3](ClO4)2=>NiCl2+6N2+6H2O+2CO+4C

[Cu(C2H4N4)2](ClO4)2=>CuCl2+4N2+4H2O+4CO or 2CO2+2C at high density

Microtek - 2-5-2024 at 22:54

I tried copper, cobalt, zink, iron(III), nickel, aluminum and magnesium as the central ion in 4-amino-1,2,4-triazole complexes with perchlorate anions some weeks ago. Al and Mg does not seem to give anything. I didn't really expect them to, but it rarely hurts to try.
The copper complex seems fairly soluble, but does give an energetic precipitate that explodes on heating wrapped in Al foil, though nothing spectacular.
The cobalt complex seems to be very insoluble, and gave a high yield of very fine cream precipitate. I did a second run with slow addition of the cobalt ions to a hot, stirred solution of ATrz and NaClO4, and cooled slowly with continued stirring, and this gave a slightly more coarse powder that could more easily be filtered. I ran it through the plate dent test after discovering that I could not set it off by mechanical stimulus, either by manual hammer blows on my anvil, or by the oblique abrasive pendulum impact test at 5.5 J (the highest setting of my apparatus). In the plate dent test, it performed disappointingly - somewhere in the vicinity of TNT, possibly due to a surprisingly low density of 1.58 g/cc. The nickel complex seemed most promising as it is non-hygroscopic, insensitive and undergoes DDT in 20 mg amounts when lightly confined. I haven't tested the actual initiating ability yet, nor the power in the plate dent test.

Yorty2040 - 25-5-2024 at 09:35

Has anyone done any work on metal-ligand complexes between a metal perchlorate and melamine?

Melamine could conceivably act as a bridging ligand between two (or maybe even three) metal centers and increase the density of the product compared to aminoguanidine perchlorate complexes, while not being much more challenging to prepare.

[Edited on 26-5-2024 by Yorty2040]

dettoo456 - 25-5-2024 at 19:24

Melamine itself has solubility issues in water, so a salt would be needed, and I don’t know how prone such a salt would be to hydrolysis. I don’t have any melamine, but I do have some acetoguanamine, so I might try to mess with that and see if anything promising is yielded.

[Edited on 26-5-2024 by dettoo456]

Etanol - 4-6-2024 at 12:01

Thanks for the idea. Ligand replacement is a real breakthrough in the synthesis of metal complexes. It works!
I successfully prepared copper-bis(4-amino-1,2,4-triazole) perchlorate from [Cu(NH3)4](ClO4)2 by reaction:
[Cu(NH3)4](ClO4)2+2ATrz=>[Cu(ATrz)2](ClO4)2+4NH3
[Cu(NH3)4](ClO4)2 was dissolved in hot water, ATrz was added, then the water is depressed with a hair dryer. Dirty blue powder has formed.
I cannot call the [Cu(NH3)4](ClO4)2 a primary explosive. But despite the poor oxygen balance ATrz complex without a shell in an amount of 50-100 mg burns a very sharp bright flash. I think, placed in the shell is quite suitable.
The substance is not sensitive to friction. 10-20 mg placed in foil burns sharply when heated, but detonates when hit with a hammer on a steel plate.

upd 50mg dried subs detonated without shall!

[Edited on 4-6-2024 by Etanol]

Etanol - 6-6-2024 at 10:52

Quote: Originally posted by Etanol

[Cu(NH3)4](ClO4)2+2ATrz=>[Cu(ATrz)2](ClO4)2+4NH3

[Ni(4-aminotriazole)3](ClO4)2 was obtained in the same way. As you said, it does not detonate without a shell, but 30-50 mg in foil detonate when heated.

How about [Cu(Diaminourea)2](ClO4)2 and [Ni(Diaminourea)3](ClO4)2? Is it stable with long storage? Is it oxidized by oxygen of air? Hydrolysis?

[Cu(aminourea)2](ClO4)2 and [Ni(aminourea)3](ClO4)2?

Is there a way to make [Cu(aminourea)2](ClO4)2 and [Ni(aminourea)3](ClO4)2 from Semicarbazide Hydrochloride?

dettoo456 - 6-6-2024 at 19:09

Carbohydrazide (1,3-diaminourea) can be prepared by amination of Semicarbazide with Hydrazine or just by amination of urea with a large excess of hydrazine. These amination reactions though, can be complex and will result in aqueous mixtures of Urea, Semicarbazide, Carbohydrazide, and Hydrazodicarbonamide. If you want a source for Carbohydrazide, pyrohobby.ru might still have some for sale, but they have a horrible payment system that isn’t secure at all.

trisCarbohydrazide Nickel diPerchlorate (NiCP) apparently works as a decent primary (and is likely stable enough in storage) to function in detonators as mentioned in some Chinese patents, but at least the trisCHLORATE (NiCC) analogue is also a strong performer; see thread: http://www.sciencemadness.org/talk/viewthread.php?tid=159732

The Cu complex may work as well, though I have no idea and don’t plan to test it. Carbohydrazide is a pain to try to make, at least for me.

[Edited on 7-6-2024 by dettoo456]

Attachment: Tris carbohydrazide nickel perchlorate (NCP).pdf (32kB)
This file has been downloaded 175 times

Attachment: Hydrazodicarbonamide.pdf (300kB)
This file has been downloaded 168 times

[Edited on 7-6-2024 by dettoo456]

[Edited on 7-6-2024 by dettoo456]

Etanol - 9-6-2024 at 00:07

trisCarbohydrazide Nickel diPerchlorate (NiCP) apparently works as a decent primary (and is likely stable enough in storage) to function in detonators as mentioned in some Chinese patents, but at least the trisCHLORATE (NiCC) analogue is also a strong performer; see thread: http://www.sciencemadness.org/talk/viewthread.php?tid=159732

Thanks. I understand correctly that carbohydrazide (diaminourea) is more stable than semicarbazide (aminourea)?

dettoo456 - 9-6-2024 at 11:29

Chemically, Semicarbazide is more stable. The hydrazine bond is less stable than the simple amide. But, Carbohydrazide will of course be better as a fuel, due to the higher energy of the 2 N-N bonds.

Etanol - 9-6-2024 at 13:11

Chemically, Semicarbazide is more stable. The hydrazine bond is less stable than the simple amide. But, Carbohydrazide will of course be better as a fuel, due to the higher energy of the 2 N-N bonds.

It seems strange to me that carbohydrazide is sold in free form, but semicarbazid is sold only in the form of hydrochloride.

dettoo456 - 9-6-2024 at 16:55

Both exist as solids at STP, but Semicarbazide is likely just too hygroscopic and basic, so it’d form hydrated solutions and/or carbonates. Same as Aminoguanidine and guanidine.

Etanol - 23-6-2024 at 06:09

What is the solubility of copper glycinate-perchlorate?
How fast is its DDT? Is it detonate unconfined or only in a strong metal shell?

I tried to prepare copper glycinate-perchlorate with electrolysis of the equimolar mixture of glycine and NH4ClO4 until hydrogen stopped released. Then I filled the solution from copper powder, flawed it and dried. Blue non-crystall powder formed, which is not detonate without confined. However, it burns better than copper tetraammine perchlorate.

Null - 8-8-2024 at 21:10

Quote: Originally posted by snooby

Okay guys,

ICM 103 is something nobody of us would like to try out. The pyrazole stuff seems inpossible to get hands on. However, I can buy IT and ship it around the world. Price is around 1000 dollars for 500 grams (WTF). And if I lower the price would increase (50 grams are 380 dollars). So, are there 3 or 2 other guys/girls who would like to share the costs? Price would be around 200 dollars for 100 grams. That's a LIFE supply. I AM willing to receiver the order and ship IT around our globe. Sent me an PM if you would like to join. Only first 3 guys can get involved.

Hope this is still relavent to the thread, but it appears there is a decent place to get a precursor for this at chem impex for less than $100 for 100g.

dettoo456 - 9-8-2024 at 06:36

I hate to rain on your parade but there are far cheaper, easier to mfg, less toxic, and better performing EMs out there compared to this esoteric primary; AgNTz, BNCP, DBX-1, or even micronized PETN/C. Most of the ‘next-gen’ EMs are just thought up and pushed by military contractors to win outrageously expensive contracts for the way too expensive compounds they plan to make.

I.E., LLM-105 is nothing special in terms of performance, sensitivity or environmental safety, and yet is somehow being made in bulk because a company convinced a general somewhere that it’s God’s gift to man - even though they’ll require $1000s in taxpayer dollars to produce something like 90g for a hand grenade. Same issue with Cl-20.

If this precursor was some obscure phenethylamine or indole that’d produce a highly active serotonin moderator

, then maybe that ‘investment’ would be worth it.

Also, Chemimpex along with companies like Chemdirect only ship to commercial addresses - and that’s almost universal for all chem suppliers nowadays.

Null - 9-8-2024 at 21:00

Yep, you're right. I only focused on the pricing and not the delivery requirement. I have had a few companies allow me to use "Individual" for the company, but you're probably right in this not being one of them.

I will try with something innocuous, but yeah, I was too money focused on that.

dettoo456 - 9-8-2024 at 21:33

I was able to get some personal chemical orders shipped to my work’s building from chemimpex, chemdirect, and thermo, and you might have luck with that too depending on your job, but you’d need to sort it all out beforehand of course (billing and end-use auth).

Good luck with whatever EM research or precursor procurement you’re looking into though

Etanol - 5-9-2024 at 12:15

The cobalt complex seems to be very insoluble, and gave a high yield of very fine cream precipitate. I did a second run with slow addition of the cobalt ions to a hot, stirred solution of ATrz and NaClO4, and cooled slowly with continued stirring, and this gave a slightly more coarse powder that could more easily be filtered. I ran it through the plate dent test after discovering that I could not set it off by mechanical stimulus, either by manual hammer blows on my anvil, or by the oblique abrasive pendulum impact test at 5.5 J (the highest setting of my apparatus). In the plate dent test, it performed disappointingly - somewhere in the vicinity of TNT, possibly due to a surprisingly low density of 1.58 g/cc.

Hmm, Co(II) or Co(III) ?
Co(II)- 4-ATRz-ClO4 complex may be very powerful.
CoCO3+2HClO4=>Co(ClO4)2+CO2
Co(ClO4)2+NH4ClO4+NH3(excess)+H2O2=>[Co(NH3)6](ClO4)3 red solution
[Co(NH3)6](ClO4)3+3 (4-ATrz)=(boiling?)=>[Co(4-ATRz)3](ClO4)3

Etanol - 15-9-2024 at 02:39

Quote: Originally posted by Etanol

The subs is a dark-red resin or red-brown grains that easily melt into red resin. When cooling, the resin turns into a red vitreous mass. The substance is poorly soluble in cold water and insoluble in isopropyl alcohol.
It is difficult to ignite. Unconfined, it melts first, then burns with flashes and burns out. The melting temperature is lower than the decomposition temperature.
Unconfined, being heated on a metal foil, it melts, then burns with a flash.
Approximately 20-30 mg, confined into aluminum foil, strong detonate when heated.
In my opinion, this is powerful, but unsuitable subs.

MineMan - 30-9-2024 at 14:03

Quote: Originally posted by Etanol

Compared to what? If it is safe and powerful enough to initiate why are you disappointed?

dettoo456 - 4-11-2024 at 07:20

Probably because it seems to just have too low of a DDT. The most promising primaries deflagrate on open flame contact or directly detonate. This stuff seems too poorly characterized (as of now) and the fact that it melts before fully decomposing is unfavorable in general.

It could have promise though, as you suspect. Cation or anion swapping for EM complexes is always a possible pathway to find good candidates for use. Perhaps the Ag, Ni, Fe salts of BrO3, IO4, NO3, etc.

Long life, short list

pdb - 17-11-2024 at 08:05

Energetic materials have been a hobby of mine for several decades. Especially primary explosives, due to their diversity and their ability to achieve DDT, which I find fascinating. As far as I know, the phenomenon that produces a shock wave in a few milligrams of primary explosive from a flame is not yet fully understood.

What I find ironic is that this passion doesn’t involve thousands of products but only a small number, even though, in chemistry, the substances capable of exploding number in the tens of thousands. Personally, I believe I have prepared fewer than twenty primary explosives in total, which I list here:

Pb(N3)2
Hg(N3)2
AgN3
Cd(N3)2
Hg(CNO)2
AgCNO
Ag nitrotetrazole
Ag azotetrazone
Ag2C2
Ag2C2·AgNO3
TATP
HMTD
DBX-1
DDNP
Tetracene
C3H12 cyanuric triazide
3-nitrobenzenediazonium perchlorate (CAS 22751-24-2)
2,4-Dinitro-benzenediazonium perchlorate (CAS 197637-25-5)

It’s not a lot, but it has been enough to keep me captivated for thousands of hours in my life. What should one make of this? Is it absurd and sad, or just original, like other more popular passions, such as music, painting, sports, etc.?

greenlight - 17-11-2024 at 09:52

There's a lot of hobbies out there that are much stranger than synthesising and testing energetics. It is quite unique due to the danger involved and illegality in most countries which is enough to deter the majority of people. Embrace it I say, as long as your doing it safely, it's definitely something different, I have been interested for nearly two decades and on and off experimenting when I can.

You've got quite an extensive list of primaries there. I have only made a few of them as I have always used them mainly for initiation of secondaries.

We do have some theories on the DDT transition.

When dealing with primaries like TATP or HMTD you may have noticed that the same unconfined pile that poofed underwent DDT when confined in even an open ended paper tube. In small amounts in the open, the gases are able to expand freely whereas in any spatial confinement they reflect and form turbulences which increase flame velocity. This exponential rise in flame temperature and resulting gas pressure is thought to be responsible for the transfer to detonation. Most likely when a certain temperature is reached or a certain speed of flame front (speed of sound).
When you have a large enough unconfined pile, just the weight of the explosive would be enough to cause this effect as well.

As for the primarys like azides which detonate in absolutely tiny quantities the cause is theorised to be the N3 ion. Two of the nitrogen can form stable N2 gas but the third nitrogen atom is expelled along with a considerable quantity of energy. This lone nitrogen can react with another N3 ion in the vicinity. If you can imagine this all happening in one small spot with millions of N3 ions decomposing simultaneously and all forming nitrogen gas plus a lone reactive nitrogen the rapid ly violent DDT transition for say lead azide makes sense. There's more to it as its broken down into two seperate reactions, this is just what I can recall at the moment.

Etanol - 17-11-2024 at 13:06

DBX-1

2,4-Dinitro-benzenediazonium perchlorate (CAS 197637-25-5)

Wow! Can you say anything about the properties of this? Hygroscopicity, solubility, stability, DDT?

Dinitro-benzenediazonium perchlorate

pdb - 17-11-2024 at 14:39

I hesitated to include it in my list of primaries because I’ve never managed to achieve DDT in open air. The substance deflagrates, leaving a combustion residue, but doesn’t detonate.

I even tried initiating it with another primary. The photo shows a trail of 2,4-Dinitro-benzenediazonium perchlorate ("DNBDP") interrupted in the middle by 50 mg of nitrobenzenediazonium perchlorate, which constitutes a pretty powerful initiation. The fire was set at one end, and you can see that the detonation at the center failed to propagate to the rest of the DNBDP.

Microtek, who also prepared it, said that DBBDP could achieve DDT, but neither Axt nor I have been able to make it detonate.

pdb - 17-11-2024 at 14:53

Quote: Originally posted by greenlight

We do have some theories on the DDT transition.

Yes, of course, when the configuration of the charge creates confinement—either because it is contained in an enclosure or under its own weight—the accumulation of combustion gases and the heat released can lead to the formation of a shock wave. Even a low explosive can be made to detonate under certain conditions.

But the question is different when a few milligrams deposited without any compression on a metal plate manage to dent or puncture it. What you say about the N3 radical, where the ejection of one nitrogen atom impacts another N3, merely describes a chain reaction. However, the majority of chain chemical reactions occur without detonation, so IMO this explanation is not sufficient to account for the behavior of primaries.

Etanol - 18-11-2024 at 03:30

I hesitated to include it in my list of primaries because I’ve never managed to achieve DDT in open air. The substance deflagrates, leaving a combustion residue, but doesn’t detonate.

I even tried initiating it with another primary. The photo shows a trail of 2,4-Dinitro-benzenediazonium perchlorate ("DNBDP") interrupted in the middle by 50 mg of nitrobenzenediazonium perchlorate, which constitutes a pretty powerful initiation. The fire was set at one end, and you can see that the detonation at the center failed to propagate to the rest of the DNBDP.

This is strange. Such properties can only occur if the product does not correspond to the formula of 2,4-Dinitro-benzenediazonium perchlorate.

But the question is different when a few milligrams deposited without any compression on a metal plate manage to dent or puncture

It appears that rapid DDT requires the presence of chemical bonds with positive enthalpy and low activation energy that can be converted into detonation products in 1-3 molecular collisions.
This contributes to a small critical detonation diameter and low detonation excitation pressure.

Axt - 18-11-2024 at 04:41

Good god pdb, it's been just shy of 20 years it's good to see you made it to 75 posts haha. This is off topic though, it's not a complex salt and the original thread is here http://www.sciencemadness.org/talk/viewthread.php?tid=3681 . Yes, I made the dinitrobenzenediazonium perchlorate and yes its ability to DDT is lower than that of the less nitrated homologues. Its counter intuitive for numerous reasons but is clearly shown in practice. It's likely due to balance between the electron deficient diazonium group and the electron withdrawing nitro groups creating a stronger bond overall. Most sensitive to least is benzene>nitrobenzene>dinitrobenzene, a clear pattern with the worst of all being the benzenebis(diazonium) diperchlorate derived from phenylenediamine which likes to detonate in solution. On the other side, one would expect electron donating groups such as methyl (aminotoluene) to create a more sensitive diazonium salt than even that of benzene.

I'm not sure what your photo is showing btw, it looks like an orange blob taped to the middle of some angle iron. I've never confined dinitrobenzenediazonium perchlorate but assumed it would DDT given any excuse with confinement.

[Edited on 18-11-2024 by Axt]

greenlight - 18-11-2024 at 09:46
